Charger/Converter VICTRON ENERGY MultiPlus 12|1200|50

When storage and power are synonymous.

The result of Victron's expertise and know-how, the MultiPlus charger/converter combo combines a 50A 12V charger and a 230V sine wave converter in a single box. All managed automatically by an ultra-fast transfer switch!

A genuine electrical management system, the MultiPlus inverter/charger will take care of optimising energy distribution and storage for you: plug into the public grid, a campsite socket or similar, and the MultiPlus will take care of the rest. The accumulated electricity will be stored in your vehicle's auxiliary batteries, while external energy is automatically prioritised to power your electrical appliances.

Thanks to the ultra-fast switch, you can switch from charger mode to inverter mode in less than 20 seconds. Perfect for protecting your fridge-freezer or any other appliance sensitive to power cuts. It's also ideal for watching TV or surfing the web without worrying about being cut off!

This 1200VA model can be paralleled with 5 other MultiPlus units for increased power output.

Equipped with an automatic search mode, the inverter has low power consumption when no appliance is connected to it. For unlimited road-trips!

Technical specifications

• Power Control / Power Assist
• Transfer switch: 16A
• Supply voltage range: 9.5 - 17V
• Output voltage: 230VAC
• Continuous output power: 1000W at 25°C
• Peak power: 2400W
• No-load power consumption: 13W (4W in search mode)
• Charger current: 50A
• Absorption charging voltage: 14.4V
• Float charge voltage: 13.8V
• Storage mode: 13.2V
• Battery temperature sensor supplied
• V.E. Bus communication port (for parallel or three-phase operation + system integration)
• Battery connection: up to 35mm² (depending on the length of cable required for your installation)
• Weight: 8.2 kg
• Dimensions: 406 x 250 x 100 mm
