Safety first

Compatible with a 12v or 24v battery bank, this BlueSolar PWM LCD-USB 5A controller from Victron Energy converts the energy produced by solar panels. Thus avoiding any overcharging of your battery.

And even more productivity

Easy to install, the BlueSolar PWM 5A automatically detects the input voltage of your solar panels (12v or 24v). Then configure it using the LCD screen and you're done! The "Bulk, Absorption, Float" charging process will then intelligently manage the recharging of your secondary battery, offering it increased efficiency and extended lifespan.

Two integrated USB ports will also allow you to charge your electronic devices on a daily basis. Ideal for a solar kit installed in your converted van!

Technical specifications

• Voltage: 5V
• Capacity at 12V: 60W of solar panels - Maximum solar voltage: 28V
• Capacity at 24V: 120W of solar panels - Maximum solar voltage: 55V
• Compatible with GEL, AGM, liquid electrolyte or LiFePO4 batteries (with integrated BMS only)
• Overcharge protection
• Liquid crystal display screen
• USB outputs x2
• Day/Night option for load output
• Operating temperature: -35°C to +60°C
• Terminal size: 6mm²
• Weight: 150g
• Dimensions (h x w x d): 96 x 169 x 36 mm
